| LGA1151 socket for 6th Generation Intel® Core™ i7/ i5/ i3/Pentium®/Celeron® Processors | |
| Supports 14nm CPU | |
| Supports Intel® Turbo Boost Technology 2.0* | |
| * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. | |
| ** Refer to www.asus.com for Intel® CPU support list. | |
| Chipset | Intel® H110 Express Chipset |
| Memory | 2 x DIMMs, max.32GB, DDR4 2133 MHz, non-ECC, un-buffered memory |
| Dual channel memory architecture | |
| Supports Intel® Extreme Memory Profile (XMP) | |
| * Refer to www.asus.com for the Memory QVL (Qualified Vendors List). | |
| Expansion Slots | 1 x PCI Express 3.0/2.0 x16 slot |
| Graphics | Integrated Graphics Processor- Intel® HD Graphics support |
| Multi-VGA output support :HDMI/DVI-D/D-Sub ports | |
| - Supports HDMI with max. resolution 4096 x 2160@24Hz / 2560 x 1600@60Hz | |
| - Supports DVI-D with max. resolution of 1920 x 1200 @60Hz | |
| - Supports D-Sub with max. resolution 1920 x 1200@60Hz | |
| Supports Intel® InTru™ 3D/Quick Sync Video/Clear Video HD Technology/Insider™ | |
| Supports up to 2 displays simultaneously | |
| Maximum shared memory of 1024MB | |
| Storage | Intel® H110 Express Chipset |
| - 4 x SATA 6.0 Gb/s ports | |
| LAN | Realtek® 8111H Gigabit LAN controller |
| Audio | Realtek® ALC887 8-channel high definition audio CODEC |
| - Supports jack-detection and front panel jack-retasking | |
| USB | Intel® H110 Express Chipset |
| - 4 x USB 3.0 ports (2 ports at mid-board, 2 ports at back panel) | |
| - 6 x USB 2.0 ports (2 ports at mid-board, 4 ports at back panel) | |
| Back Panel I/O Ports | 1 x PS/2 Combo port |
| 1 x HDMI port | |
| 1 x DVI-D port | |
| 1 x D-Sub port | |
| 1 x LAN (RJ-45) port | |
| 4 x USB 2.0/1.1 ports | |
| 2 x USB 3.0/2.0 ports | |
| 3 x Audio jacks support 8-channel audio output | |
| Internal I/O Connectors | 1 x USB 3.0/2.0 connector support additional 2 USB 3.0/2.0 ports |
| 1 x USB 2.0/1.1 connector support additional 2 USB 2.0/1.1 ports | |
| 4 x SATA 6Gb/s connectors | |
| 1 x 4-pin CPU Fan connector | |
| 1 x 4-pin Chassis Fan connector for 4-pin PWM & DC mode | |
| 1 x Front panel audio connector(s) (AAFP) | |
| 1 x System panel connector | |
| 1 x 24-pin EATX Power connector | |
| 1 x 4-pin EATX 12V Power connector | |
| 1 x Chassis Intrusion connector | |
| 1 x Speaker connector | |
| 1 x COM header | |
| 1 x Clear CMOS jumper | |
| 1 x 14-1 pin TPM header | |
| ASUS Exclusive Features | ASUS 5X PROTECTION II |
| - ASUS LANGuard - Protects against LAN surges, lightning strikes and static-electricity discharges! | |
| - ASUS Overvoltage Protection - World-class circuit-protecting power design | |
| - ASUS DIGI+ VRM - 3+2+1 Phase digital power design | |
| - ASUS DRAM Overcurrent Protection: Enhanced DRAM overcurrent protection | |
| - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! | |
| Superb Performance | |
| - ASUS EPU | |
| - ASUS USB 3.0 Boost | |
| - PC Cleaner: Fast and easy way to get rid of unnecessary junk files | |
| Media Streamer | |
| - Pipe music or movies from your PC to a smart TV, your entertainment goes wherever you go! | |
| - Media Streamer app for portable smartphone/tablet, supporting iOS 7 & Android 4.0 systems | |
| ASUS Exclusive Features | |
| - ASUS Ai Charger | |
| - ASUS AI Suite 3 | |
| - Anti Surge | |
| EZ DIY | |
| Push Notice | |
| - Monitor your PC status with smart devices in real time | |
| UEFI BIOS EZ Mode | |
| - Featuring friendly graphics user interface | |
| - ASUS CrashFree BIOS 3 | |
| - ASUS EZ Flash 3 | |
| ASUS Q-Design | |
| - ASUS Q-DIMM | |
| Quiet Thermal Design: | |
| - ASUS Fan Xpert | |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control |
| Manageability | WfM 2.0, DMI 2.0, WOL by PME, PXE |
| Accessories | 2 x Serial ATA 6.0Gb/s cables |
| 1 x I/O shield | |
| 1 x User´s manual | |
| Support DVD | Drivers |
| ASUS Utilities | |
| ASUS Update | |
| Anti-virus software (OEM version) | |
| Operating System Support | Windows® 10* |
| Windows® 8.1* | |
| Windows® 7 | |
| *64-bit supported only | |
| Form Factor | Mini-ITX Form Factor, 6.7”x 6.7” (17cm x 17cm) |
-/-
